BC Racing BR-Series Coilovers Toyota Crown Majesta JZS177 99-04

BC Racing BR-Series Coilovers for Toyota Crown Majesta JZS177 (1999-2004) – Height and Damping Adjustable, Corner Weight Adjustable

These BC Racing BR-Series coilovers replace the standard dampers and springs on the Toyota Crown Majesta JZS177 (1999-2004) with a fully adjustable setup. You can set the ride height, damping and corner weights to suit the car, making them ideal for fast road driving and track days.

The BR-Series is built around a 46mm piston in a 53mm monotube damper body. The extra oil capacity lowers peak temperatures, so damping stays consistent when the car is driven hard for long periods. Damping is set with a single 30-way adjuster that controls rebound and compression together.

Ride height is set by winding the bottom mount up or down the damper body rather than moving the spring, so full damper travel is kept whatever height you run. The lower spring platform also adjusts, so the car can be corner weighted for even tyre loading across each axle.

Specifications

• Damping: A single 30-way adjuster that sets rebound and compression together
• Spring rates: 10/7kg/mm (F/R)
• Front: Includes rubber top mount
• Rear: Includes rubber top mount or no top mount
• Kit weight: 23kg

Key Features

• 30-way damping adjustment through a single adjuster
• 46mm piston in a 53mm monotube damper body for consistent damping
• Ride height set at the bottom mount, so full damper travel is kept at any height
• Adjustable lower spring platform for corner weighting
• Bearing mounted upper front spring platform (where fitted)
• Dust boots to protect the damper seals
• Black chromed damper bodies with anodised aluminium parts for corrosion resistance

What's in the Kit?

• 2 x front coilovers with springs (includes rubber top mount)
• 2 x rear dampers and springs (includes rubber top mount or no top mount)

Fitment

• Toyota Crown Majesta JZS177 99-04 (RWD)

Not suitable for: other Toyota Crown Majesta JZS177 variants with a different drive layout, strut diameter or rear suspension type. Please check your chassis code and drive type against the fitment above before ordering.

Installation

The coilovers replace the standard dampers and springs and bolt in to the original mounting points. Set the ride height and spring preload before final tightening, let the suspension settle, then recheck the height and have a four-wheel alignment carried out. We recommend professional fitting.

Upgrade Further

Other BC Racing options for this car: BC Racing DS-Series Coilovers Toyota Crown Majesta JZS177 99-04 RWD 14/10kg. Keep a spare BC Racing C-spanner for adjusting the height and spring platforms.

Can I adjust the ride height?

Yes. Ride height is set by moving the bottom mount on the damper body, so you keep full damper travel at any height you choose.

How is the damping adjusted?

The BR-Series uses a single 30-way adjuster that sets rebound and compression together. Start from BC's base setting and adjust front and rear in small steps to suit the road or track.

Are these suitable for daily driving?

Yes. Set to a sensible height and softer damping, they work well on the road while giving sharper handling than standard.

Can I get different spring rates?

The kit comes with 10/7kg/mm (F/R) springs as standard. If you need different rates, contact us before ordering and we will check what is available.

Do I need a wheel alignment after fitting?

Yes. Changing the ride height alters the suspension geometry, so a four-wheel alignment should be carried out once the car has settled.

What warranty is included?

BC Racing products are covered against defects in materials and workmanship. Contact us if you have any problem with your kit.
